Stainless steel pressure gauge 6 Bar dn 63mm u-clamp

63SA6.35
New

Dimensions: B=29mm D=62mm D1=68mm H=56mm

help_outlineAsk about product
Stainless steel pressure gauge 6 Bar dn 63mm u-clamp

Stainless steel pressure gauge 6 Bar dn 63mm u-clamp



  Shipping Policies

Goods travel on behalf of and at the risk of the purchaser. Any damage or tampering occurring durin

  Returns Policies

The customer, with reference to the Legislative Decree of 22 May 1999, n. 185, you can exercise the

€53.00
No tax
Certificates: NO
Front Flange: NO
Seal: NO
Glycerine filling: NO
Oxygen degreasing: NO
Quantity

All stainless steel pressure gauge diameter 63mm range 0/6 Bar with u-clamp available also with glycerine (see options)
Suitable for corrosive process gas or liquid. With liquid filled case for applications with high dynamic pressure pulsations or vibrations. Chemical/petrol-chemical, power stations, mining, on- and offshore, environmental technology, mechanical engineering and plant construction.

All stainless steel pressure gauge made according UNI EN 837.1 norms - case aisi 304 dial 63mm. - Stainless steel aisi 316 movement and pivot - BACK cilindrical connection 1/4 bspp (ISO 7/1)- Aluminium dial White background Black - BAR scale and Red PSI - Accuracy 1,6% - Aluminium index

Working Temperature: Room-Temp. -30 +65° C (-22 +149° F) - With Glycerine -10 +65° C (+14 +149° F)
Process -40 + 180° C (-40 +356° F) - With Glycerine 0 + 75°C (+32 +167° F)
Working Pressure: Steady 75% - Variable 60%
Overpressure not admitted


If you wish a customized offer for large quantities or dials with your logo Contact us

Bart
63SA6.35

Data sheet

Diameter
63mm
Connection position
Posteriore + Staffa ad U
Range
0/6 Bar
New
